Think, create, Elastollan®
Thermoplastic Polyurethane
Elastollan® is the brand name for thermoplastic polyurethane (TPU) from BASF. Over the last few decades, the numerous benefits of Elastollan® in all its forms – aromatic or aliphatic, very soft or glass fiber-reinforced, flame retardant or highly transparent – have been clearly demonstrated across every sector of industry.
Key Advantages of Elastollan®
- High wear and abrasion resistance
- High tensile strength and excellent tear resistance
- High resistance against oils, greases, oxygen, and ozone
- Very good low-temperature flexibility
- Very good damping capacity
Elastollan®
Elastollan® is the brand name for thermoplastic polyurethane (TPU) from BASF. It stands for maximum reliability, consistent product quality and cost efficiency. Elastollan® can be extruded into hoses, cable sheathing, belts, films and profiles, and can also be processed using blow molding and injection molding technologies.
This extensive product portfolio, which makes use of a variety of raw materials and formulations, is the starting point for successfully bringing innovative customer projects to fruition.
We thrive on creative ideas and complex challenges – come and talk to us!
Material Properties
Processing Recommendations
Our Elastollan® Innovations
All-rounder Elastollan®
Product Range Thermoplastic Special Elastomers
| Series Type | Chemistry | Shore Hardness | Range Properties |
| 11 | Ether | 70 A to 75 D |
Excellent hydrolysis resistance, cold flexibility, resistance to microorganisms |
| 11 FHF |
Ether flame retardant | 75 A to 54 D | Non-halogen-based flame retardant, outstanding mechanical properties, excellent hydrolysis resistance, resistance to microorganisms |
| 12 | Ether | 85 A to 83 D | Highly transparent, excellent hydrolysis resistance, cold flexibility, resistance to microorganisms |
| 12 FHF | Ether flame retardant | 70 D to 80 D | Non-halogen-based flame retardant, outstanding mechanical properties, high rigidity, excellent hydrolysis resistance, resistance to microorganisms |
| 13 | Ether |
85 A to 90 D | Water-vapor permeable, good tear propagation strength, very good mechanical properties |
| C | Ester | 80 A to 75 D | Excellent mechanical properties, very good damping behavior, good rebound, very good wear resistance |
| B | Ester |
80 D to 65 D | Very good mechanical properties, good cold flexibility, good wear resistance |
| S |
Ester | 70 A to 65 A | Good mechanical properties, good wear resistance, good damping behavior and rebound |
| 500 | Ester | 85 A to 65 D | Good mechanical properties, good abrasion resistance |
| 600 | Ester | 85 A to 83 D | Transparent, good damping behavior and rebound |
| 700 | Ester | 70 A to 65 A | Very good hydrolysis resistance, high wear resistance, very low compression set, very good mechanical properties |
| 800 | Ester | 75 A to 95 D | Very good transparency, good abrasion resistance |
| A | Ether or ester aliphatic | 65 A to 55 D | Color-fast, non-yellowing, hydrolysis-resistant (ether) |
| L | Ether or ester aliphatic | 75 A to 80 D | Transparent, long-term UV-stability |
| Supersoft | Ester or ether |
35 A to 65 A | Very good wet grip, very flexible, very soft in part, highly transparent in part, ESD grades with very good volume resistivity |
| HPM | Ester | 60 A to 55 D | Very good damping behavior and rebound, high temperature resistance, improved setting behavior, good demolding properties, color-fast, soft touch |
| HFFR | Ether flame retardant | 85 A to 92 A | Non-halogen-based flame retardant, increased flame retardancy, reduced smoke density and toxicity |
| CS | Ester | 70 A to 65 D | Very good compression set, extremely low creep behavior |
| R | Ester-reinforced | E-modulus 1000-17000 MPa |
Glass fiber-reinforced, very high stiffness, low thermal expansion coefficient, low shrinkage, very good impact resistance |
| Food Contact (FC) | Ester or ether | 70 A to 75 D | Basic suitability for food contact applications in FDA and EU-regulated markets (see Food Contact Information) |
| Hotbond | Ester | see technical product info | Excellent adhesive properties, good solubility with a broad viscosity range |
| Bondura | Ester | see technical product info | Excellent adhesive properties, low activation temperature, good solubility with a broad viscosity range |
| 15 | Ether | 98 A | Excellent hydrolysis resistance, cold flexibility, resistance to microorganisms combined with an outstanding burst pressure and low creep behavior at elevated temperatures |
| N | Ether (Ester possible, on request) | 85 A to 95 A | biobased, identical performance to equivalent fossil Elastollan grades |
Product Range Overview
Especially suitable for these Industries
Because of its unique property profile Elastollan® is particularly suitable for the use in the following industries.
Elastollan® Application Range
The applications are as manifold as its product properties: Explore the various application possibilities of Elastollan®!
Our Service Package
We offer our customers a comprehensive range of services with leading technologies and products. Find the service that matches your needs!
Innovative Products
In addition to Elastollan® we offer further innovative materials. These might also be interesting for you.
Tailor-made Solutions
Tailor-made for individual needs: We support our customers in developing application-oriented solutions.
Processing of Elastollan®
The following methods can be used for the processing of Elastollan®.
