September 16, 2020

Ultrasim®: Simulation now for elastomers

  • Simulation for thermoplastic elastomers available now
  • Applicable in all stages from initial processing to the final product
  • Simulation options include cyclic load situations


BASF expands the application range of its simulation tool Ultrasim®: as of now, the CAE tool also calculates component concepts based on elastomers, especially Elastollan®, BASF’s thermoplastic polyurethane (TPU). The simulation covers the entire process chain from initial processing to the mechanical properties of the final product. Among the special features of the simulation with Ultrasim® are options to simulate both the initial load and cyclic loads of a component. The calculation of component concepts based on elastomers with Ultrasim® is now available.

The property profile of elastomers typically includes stress softening (Mullins effect) under cyclic loading. For reliable simulation results, the consideration of this material behaviour is indispensable. Ultrasim® allows the precise description of stress softening during a cyclic course of loading.

Exact forecast of material behavior

However, the simulation usually starts in the stage of initial processing, delivering an exact forecast of the warpage behavior during injection molding, considering the complex visco-elastic behavior of the material. The simulation with Ultrasim® is now available for several Elastollan® grades. Further grades are currently in the characterization process.

Shorter development times with Ultrasim®

“The simulation tool Ultrasim® provides our customers with quick and reliable information about how BASF materials behave in their planned components, during production as well as at a later stage during service life. Customers who apply Ultrasim® instead of constructing prototypes or carrying out tests can significantly shorten their development times. This simulation support is now also available for Elastollan®”, says Achim Besser, Team Leader Material Modelling in BASF’s Performance Materials division. BASF ist the first material producer offering such wide-ranging simulation services in the TPU sector.

Elastollan® is used in automotive parts such as strain relief sleeves on electric connectors, spring isolators at the axles, folding bellows and end stops for shock absorbers. In interior parts, door handles and gear knobs are produced with TPU. Beyond that, Elastollan® is frequently employed in the consumer goods sector: application examples include ski boots, shoe soles and cable sheathings.
